Quantum Edge 3
Brand: Quantum Wheelchairs
Categories:
The Quantum Edge® 3 offers some of the best power chair experience ever! Upgraded SRS (Smooth Ride Suspension) gives a smooth, comfortable ride and advanced stability. Optional iLevel® is available at 4.5 mph with up to 12" of power adjustable seat height.
Standard features include front and rear LED fender lights, a USB charger, and drive wheel color accents. The Edge® 3 is available in a total of 20 color options, including seven brand-new, bold colors.
| Drive wheels | Standard: 35.6cm (14") solidOptional: 35.6cm (14") pneumatic |
|---|---|
| Castors | Front: 15.2cm (6") solidRear: 15.2cm (6") solid |
| Maximum speed | Up to 9.6km/hUp to 7.24km/h with iLevel activated |
| Ground clearance | 6.9cm (battery tray) |
| Turning radius (without front riggings) | 52.1cm |
| Overall length (without front riggings) | 82cm (32.23”) |
| Base width | 62.2cm (24.4”) |
| Seat width | Static seat: 10" - 22” (25.4cm - 55.9cm)Power tilt and tilt/lift: 12"-22"(30.5cm - 55.9cm) |
| Seat depth | Static seat: 10" - 22” (25.4cm - 55.9cm)Power tilt and tilt/lift: 12"-22"(30.5cm - 55.9cm) |
| Seat to floor height | Static seat: 16.5" - 18.5” (41.9cm - 47cm)Power tilt: 17.5" - 19.5” (44.5cm - 49.5cm)Lift and tilt: 17.5" - 19.5” (44.5cm - 49.5cm) |
| Manual recline | Yes |
| Battery size | NF-22 (2) |
| Battery weight | 17.24kg each |
| Available electronics | 120A Q-Logic 3 EX |
| Battery charger | 8A Off-board |
| Motor packages | Two-pole, mid-wheel drive |
| Weight capacity | 136kg |
| Base weight (without seating system) | 63kg |
