RAZ-CAT Commode

Brand: Raz

Categories:

The Raz-CAT has all of the features of the RAZ-AT but in a more compact size.

Designed for pediatrics, adolescents or smaller adults, the Raz-CAT is better suited to physically smaller clients.

Raz Mobile Shower Commodes are designed and manufactured in Canada to the highest standards with the benefit of being able to customise fit for each client.

RAZ are well known for their customisations, to view their customisations done for other clients, please click HERE to view the gallery.

You can also view the standard RAZ Accessories gallery HERE to see the range of different accessories available.

  • The base and seat frames retain the 18” width of the RAZ-AT so that the chair can still be positioned over a toilet.
  • The base frame of the RAZ-CAT has been shorted by 3”, which makes the chair more maneuverable and easier to navigate through tighter spaces.
  • The seat frame depth of the RAZ-CAT has been reduced and a depth-adjustable back offers depths from 12” to 15” (to front of frame) or up to 17” with the front of the seat overhanging the seat frame.
  • The standard seat has an elongated aperture that works with seat depths from 12” to 15”, The seats can also be custom made to size in seat width and depth, the seat aperture can also but custom shaped and sized.
  • The depth-adjustable back provides growth in the RAZ-CAT, an essential component for pediatrics.
  • Back frames can be ordered in widths 14”, 16” and 18”.
  • 15” and 18” back heights are available.

All accessories that fit the RAZ-AT can be ordered on the Raz-CAT.

SPECIFICATIONSRaz-CAT (Compact Attendant Tilt)
WEIGHT CAPACITY115 kg
FRAME WIDTH18” (46cm)
BACK WIDTH14" (35 cm), 16" (40 cm), or 18" (46 cm)
OVERALL WIDTH (with standard armpad)21.75" (55 cm), 23" (58 cm) with 18" (46 cm) wide Back frame
OVERALL LENGTH WHEN UPRIGHT32" (81 cm)
SEAT WIDTH (commode seat)18" (46 cm)

| SEAT DEPTH
(front of back post to front of seat) | 11" – 16" (28 cm – 40 cm) | | BACK HEIGHT - (top of seat to top of upholstery) | 15" or 18" (38 cm or 46 cm) | | RECLINING BACK (top of seat to top of upholstery) | 15" or 18" (38 cm or 46 cm) | | CLEARANCE HEIGHT UNDER SEAT | 16.75", 17.75", 18.75", 19.75", 20.75" (42.5, 45, 47.5, 50, 53cm) with pan brackets17.5", 18.5", 19.5", 20.5", 21.5" (44.5, 47, 49.5, 52, 54.5 cm) without pan brackets | | ARMREST HEIGHT ABOVE SEAT | (20” Adjusta-Back) 15" (38 cm) High Back: 5.5" – 8" in ½" increments (14 – 20 cm)18" (46cm) High Back: 6.5" – 9" in ½" increments (16.5 - 23 cm) | | SEAT-TO-FLOOR HEIGHT | 21.5" – 25.5" in 1" increments (55 – 65 cm) | | PRODUCT WEIGHT (with footrests) | 25 kg | | FRAME AND HARDWARE MATERIAL | Stainless Steel (Lifetime warranty against corrosion) |
